Bosch 00280796 Wire Harness (Smu) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00280796 replaces AP2804545, 280796.

Description

This wire harness connects the SMU assembly to the appliance's electrical system, restoring reliable power and signal transmission between components. Use when the SMU or control loses communication or power. What it does

• Routes power and control signals between the SMU (sump/motor unit) and the appliance control board.
• Replaces damaged, frayed, or burned wiring that can cause intermittent operation or failure to start.
• Helps eliminate symptoms such as error codes, no motor/sump activity, or loss of specific SMU functions.
• Maintains proper connector alignment and secure electrical contact for consistent performance.

What's included

• One replacement wire harness (SMU) as shown.

Install notes

• Disconnect power to the appliance before starting work to avoid shock or damage.
• Inspect connectors and mating harness on the appliance for damage; replace both sides if necessary.
• Route and secure the harness away from sharp edges, hot surfaces, and moving parts to prevent wear.
