Frigidaire 809160316 Control Board (Main Electronic Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160316 replaces AP5981980, 4247488, PS11704440.

Description

This electronic control board manages a range of appliance functions so your unit runs the selected cycles and responds to user inputs. Replacing a faulty board restores normal control and cycle operation. What it does:

• Interprets user commands and controls cycle timing and sequencing
• Sends switching signals to motors, heaters, valves, and relays
• Manages display and panel feedback so settings and status appear correctly
• Failsafe symptom examples: no response to controls, cycles won't start or advance, erratic operation, or loss of display/indicator function

What's included: One main electronic control board. Install notes:

• Disconnect power at the breaker or unplug the appliance before starting work
• Handle the board by edges and avoid static discharge; wear an anti-static strap if available
• Verify the part number on the old board before installing to ensure compatibility
