Frigidaire 5304508232 Control Board (Electronic Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304508232 replaces AP6041696.

Description

This electronic control board replaces the refrigerator's main circuit board to restore electronic control of cooling cycles and user interface functions. It helps the appliance run normal automatic defrost, temperature regulation, and system monitoring. What it does:

• Receives user inputs and sends control signals to compressor, fans, and defrost system
• Manages timed cycles and temperature setpoint responses to maintain proper cooling
• Can correct symptoms like non-responsive control panel, erratic cooling behavior, or continuous run/defrost issues when board failure is confirmed
• Works with associated sensors and relays to coordinate refrigerator operation

What's included:

• One control board assembly

Install notes:

• Only install if diagnosis confirms a faulty control board; disconnect power before servicing
• Handle the board by edges and avoid ESD (electrostatic discharge) to prevent damage
• Verify connectors and wiring harness fit before finalizing installation
• Some models may require cabinet access panels and basic tools
