Frigidaire 241633512 Control Box (Electrical Control Module) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Housing Or Cover and Refrigerator Touch Pad.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 241633512 replaces AP5780905, 241633502, 241633504, 241633506, 241633510, 3016230, PS8691992.

Description

A replacement control box that houses the appliance's electronic controls and wiring connections, restoring command of timed and powered functions. Replaces a failed or damaged control enclosure to help return normal operation. What it does

• Manages and routes electrical signals between user controls, sensors, and major components.
• Commonly replaced when the appliance has intermittent power, unresponsive controls, or erratic operation.
• Protects internal control circuitry and connector terminals from damage and wear.
• Works as the main enclosure for the appliance's control electronics and wiring harness connections.

What's included One control box (electrical control module) as shown. Install notes

• Disconnect power before servicing to avoid electric shock—always verify the appliance is de-energized.
• Suitable for technicians or experienced DIYers; follow factory service manual for access and wiring details.
• Reconnect all harnesses and secure mounting fasteners; confirm correct routing to prevent pinched wires.
