Best Seller
Manufacturer Part

Frigidaire 316557105 Clock Timer (Electronic Oven Control) OEM Part

Manufacturer's Part Number: 316557105
Genuine Frigidaire part
Appliance Compatibility Tool
No longer available

This part is discontinued by the manufacturer and is no longer available for purchase.

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316557105 replaces AP4587737, 1719790, 316418205, AH3409081, EA3409081, PS3409081.

Description

This electronic clock timer assembly replaces a failed oven control so you can set cook times, use the timer and see the clock display. It restores timer and display functions on compatible range/oven control panels. What it does:
  • Provides a digital clock display and timer functions for the oven control
  • Enables timed cooking and countdown/count-up timer features
  • Replaces a blank/incorrect clock display or non-working timer control
  • Restores user interface feedback when the original control has failed
What's included: One clock timer assembly. Install notes:
  • Disconnect power to the appliance before starting — verify with a meter or breaker off.
  • Remove the oven control panel or console to access and unplug the clock assembly; handle the display and ribbon connectors carefully.
  • Match connector type and orientation before installing; secure assembly with original screws.

Have a Repair Question? AppliancePartsPros has your Answer!

How to Replace Frigidaire 316557105 Clock Timer (Electronic Oven Control) OEM Part #316557105

Step by step instructions on how to replace a Frigidaire 316557105 Clock Timer (Electronic Oven Control) OEM Part #316557105 for Range. Note: This video is intended to give you the general idea of the part replacement procedure. Your appliance may differ depending on the manufacturer and model.

Do-It-Yourself Stories from Customers like You

Total Satisfaction Rating
5.0
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Do-It-Yourself Rating
Very Easy
Less than 15 minutes

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Frigidaire 316557105 Clock Timer (Electronic Oven Control) OEM Part

Part Number:
OEM13763220
Manufacturer's Part Number:
316557105
