Frigidaire 809019910 Main Control Board Assembly (Electronic Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809019910 replaces AP5987278, 137317201, 137317262, 809019903, 809019904, 137317200, 137317221, 4379215, 809019907, PS11728635.

Description

This main control board assembly is the appliance's electronic "brain," managing timing and power to run cycles. Replacing a failed board can restore normal operation when the unit won't start, won't advance, or behaves erratically. What it does:

• Directs cycle logic and timing for the appliance
• Distributes power to loads (motor, pump, valves, heater as applicable)
• Interprets inputs from sensors and switches and communicates status/errors
• Typical failure symptoms: won't start or power up; no response to controls
• Other symptoms: stuck mid-cycle, unexpected error codes, or components not energizing

What's included:

• 1 main control board assembly

Install notes:

• Disconnect power from the appliance before servicing; verify no voltage is present
• Handle the board by the edges and use ESD protection to avoid static damage
• Photograph wire connections and move connectors one at a time to the same locations
• Ensure all connectors are fully seated and the board is secured before restoring power
