Frigidaire 809160802 Main Control Board (Control Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160802 replaces AP5950034, 137249940, 137249910, 3447635, PS10057458.

Description

This electronic control board manages your dishwasher's cycles and powers key components. Replacing a failed board can restore proper operation when the unit won't start, is unresponsive, or won't advance through a cycle.

• Directs fill, wash, drain, and heat functions by supplying timed power to the inlet valve, circulation motor, drain pump, and heater
• Interprets inputs from sensors and the door switch to advance and complete cycles
• Common symptoms: won't start, unresponsive controls, stops mid-cycle, or cycles that won't advance
• Also shows error indications or random beeps, or fails to power components despite good wiring

What's included: 1 electronic control assembly Install notes:

• Disconnect power at the breaker before servicing; avoid moisture and live circuits
• Handle the board by its edges and use ESD protection
• Access location varies by model; transfer connectors one at a time to the matching terminals
• Ensure all connectors and mounting points are secure before restoring power and test a short cycle
