Frigidaire 809055507 Control Board (Electronic Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809055507 replaces AP5954754, 137035291, 3515922, PS10063115.

Description

This electronic control board is the appliance's "brain," directing power and timing to key components. Replacing a failed board restores proper operation, responsive controls, and reliable cycle performance. What it does:

• Interprets inputs from the control panel and sensors, then executes programmed cycles
• Distributes power to motors, pumps, valves, and other components as needed
• Manages timing, sequencing, and safety interlocks during operation
• Supports self-diagnostics; faults may present as error codes or lights
• Common symptoms of a failed board include no power, won't start, stops mid-cycle, unresponsive controls, or erratic behavior

What's included:

• 1 electronic control board

Install notes:

• Disconnect power to the appliance before servicing; observe ESD precautions when handling the board
• Photograph wiring and move connectors one at a time to the new board
• Ensure all plugs are fully seated and the board is properly mounted before reassembly
• Some models require an initialization or programming step—follow the unit's service/tech sheet after installation
