Frigidaire 809160307 Control Board (Main Electronic Control Module) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160307 replaces AP5948944, 137260100, 3515941, 7137260100, PS9865100.

Description

• Regulates compressor and fan cycling to maintain set temperatures
• Controls defrost cycles and timer functions
• Powers and communicates with the front display and touch controls
• Fault symptom linkage: needed if display is blank, buttons unresponsive, fridge won't cool, runs constantly, or shows control-related error codes

• Disconnect power to the appliance before starting work to avoid shock
• Handle the board carefully; avoid static discharge and contact with circuit components
• Photograph wiring and connector locations before removal to ensure correct reinstallation
• Reconnect all harnesses firmly and test functions after reinstall; for diagnostics if symptoms persist
