Frigidaire 809160403 Control Board (Electronic Main) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dryer Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160403 replaces AP5950031, 134994720, 3515945, PS10057455.

Description

This electronic main control board replaces the appliance's central circuit module and restores digital control of cycles, timing and user inputs. It returns responsive controls and reliable command processing for the unit. What it does:

• Manages the appliance's electronic functions, timing and user interface signals
• Receives input from buttons or touch controls and sends commands to motors, valves and relays
• Helps resolve symptoms like no display or unresponsive controls, erratic cycles, or failure to start
• Works as the central communication hub between sensors and mechanical components

What's included:

• One control board

Install notes:

• Disconnect power to the appliance before beginning any service
• Handle the board by the edges and avoid static discharge; use an anti-static wrist strap if available
• Verify connector orientation and seating; replace any broken harness clips or fasteners
