Frigidaire 809160803 Control Board (Electronic Main Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160803 replaces AP5948948, 137260140, 137260110, 137260120, 3515949, PS9865104.

Description

This is the main electronic control board that manages your appliance's cycles, display, and key functions so the unit responds correctly to user inputs and runs selected programs. What it does:

• Receives input from the console and sends signals to the motor, valves, heaters and other components
• Controls cycle timing, display messages and indicator lights
• Can cause unresponsiveness, incorrect cycles, or error codes when faulty
• May stop the appliance from starting or cause intermittent operation

What's included: One control board Install notes:

• Disconnect power before servicing to avoid electrical shock
• Handle the board carefully and avoid touching circuit traces; use ESD precautions if available
• Installation typically requires removing the console or rear access panel and unplugging ribbon/connectors
