Frigidaire 809160902 Control Board (Dishwasher) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160902 replaces AP5954758, 137260660, 3515953, PS10063119.

Description

This control board is the electronic brain of the dishwasher, managing cycle timing and power to key components. Replacing a failed board can restore normal operation when the unit won't start, behaves erratically, or won't complete cycles.

• Distributes power to the wash motor, drain pump, inlet valve, and heater as directed by the selected cycle
• Coordinates timing and sensor inputs to run and complete programs
• Issues can include no start, stopping mid-cycle, unresponsive controls with power present, or error indications
• Similar symptoms can be caused by wiring, door latch, UI board, or power issues—diagnose before replacing

What's included: One electronic control board Install notes:

• Disconnect power at the breaker before servicing; do not rely on the door switch
• Access the control (location varies by model), label/photograph connections, and transfer connectors one at a time
• Handle the PCB by the edges and observe ESD precautions
• After installation, restore power and run a test or diagnostic cycle per the service information
