Frigidaire 5304516274 Electronic Control (Control Board) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304516274 replaces AP6783486, 5304509765, 5304507614, 5304507615.

Description

This electronic control board manages cycle timing, user inputs and internal relays to control your appliance's functions. Replacing a failed control restores responsive touchpad/buttons and correct cycle operation for affected units. What it does:

• Interprets front-panel commands and runs timed sequences for cycles and heating/cooling functions.
• Switches relays to activate motors, heaters or valves as directed by the user interface.
• Common symptom fix: unresponsive controls, blank or erratic display, or cycles that won't start or complete.
• May resolve intermittent operation or unexpected shutdowns caused by a faulty control board.

What's included:

• One electronic control board (single unit as shown)

Install notes:

• Disconnect power (unplug or shut off circuit breaker) before starting any work.
• Handle the board by its edges and avoid touching connectors; observe anti-static precautions.
• Keep mounting hardware and wiring organized; reconnect all plugs exactly as removed.
