Frigidaire 5304513220 Control Panel (User Interface) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304513220 replaces AP6286074.

Description

This control panel is the user interface assembly that houses the oven/range display and touchpads, letting you select cook functions and view status. Restores responsive controls and readable display for normal operation. What it does

• Provides the front-facing buttons/touchpad and display used to set temperature, modes, timers, and clocks
• Replaces worn, cracked, or unresponsive keypads and faulty displays that prevent selecting oven or cook functions
• Helps address symptoms such as unresponsive or sticky buttons, missing or dim display segments, or intermittent control behavior
• Works as the main interface between the user and the oven/range control electronics

What's included

• One control panel user-interface assembly

Install notes

• Disconnect power at the house breaker or appliance plug before servicing to avoid shock or injury
• Handle glass, trim, and display areas carefully to avoid cracking or scratching during removal and installation
• Some models require removing the console or control housing and disconnecting a wire harness; retain all mounting screws and note connector orientation
