Frigidaire 216714600 Temperature Control Thermostat (Cold Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Freezer Temperature Control, Cold Control.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 216714600 replaces AP2113750, 890546, AH426724, EA426724, PS426724.

Description

This temperature control thermostat regulates the cabinet temperature by cycling the cooling system on and off as needed. Replacing a faulty control restores consistent cooling performance and makes the setting dial respond correctly.

• Senses cabinet temperature via the capillary bulb and opens/closes contacts to start or stop the compressor
• Corrects issues such as no cooling/won't run (open control) or running constantly/won't shut off (stuck closed)
• Addresses erratic temperatures or a dial that has little or no effect on temperature
• Helps maintain stable, food-safe temperatures once adjusted

What's included: One temperature control thermostat Install notes:

• Unplug the appliance before servicing; do not work on live circuits
• Remove the control housing/escutcheon, pull off the knob, note wire positions, and transfer any brackets as needed
• Route the new capillary in the original path; avoid kinks/sharp bends and secure the sensing bulb in the original clips
• Reassemble, restore power, and allow up to 24 hours for temperatures to stabilize; adjust the setting as needed
