Frigidaire 903160-9010 Generator & Harness (Ignition Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 903160-9010 replaces AP5650752, 2691699, 318416100, PS5574272.

Description

This ignition generator and wiring harness assembly routes power and provides the spark/ignition signal needed for gas appliance burners to light. It replaces a worn or damaged ignition assembly to restore reliable lighting. What it does:

• Sends ignition voltage to the burner igniters and electrodes so burners light reliably
• Routes and secures wiring between the control module and ignition components
• Common failure symptoms: burners won't light, continuous clicking, or intermittent ignition
• Works as the electrical interface between the control and the igniters for safe startup

What's included:

• One generator and wiring harness assembly

Install notes:

• Disconnect electrical power and turn off the gas supply before starting work
• Follow the appliance OEM diagram for correct routing and connector locations
• Inspect connectors and electrodes for damage and replace if corroded or worn
