Frigidaire 154870101 Wiring Harness (Electrical Connector Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 154870101 replaces AP5645256, 2689164, PS4704893.

Description

This wiring harness is an electrical connector assembly that routes power and signals between components to restore reliable appliance operation. It replaces damaged or worn wiring to help re-establish secure electrical connections. What it does:

• Connects power and control signals between internal components to enable normal appliance functions
• Replaces frayed, melted, or broken wires that can cause intermittent operation or failure to start
• Helps resolve flickering controls, loss of power to parts, or unreliable component response
• Maintains correct routing and connector fit to prevent shorts and poor connections

What's included:

• One wiring harness assembly

Install notes:

• Disconnect all power to the appliance before starting any repairs to avoid shock or injury
• Verify connector orientation and secure all terminal connections; do not force connectors into place
• Route the harness to match factory wiring paths and use existing clips or tie points to prevent rubbing
