Frigidaire 316510647 Wiring Harness (Control/Terminal Block), 1 Piece OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316510647 replaces AP4433250, 1513434, AH2364077, EA2364077, PS2364077.

Description

This wiring harness connects the appliance's control or terminal block to internal components so electrical signals and power reach the control system. Replacing a damaged harness restores reliable electrical connections and helps the unit operate safely. What it does

• Routes multiple wires between the control board and terminal block, burners, or sensors
• Delivers power and signal continuity to essential components
• Symptoms of a failing harness can include no power to controls, intermittent operation, or blown fuses
• Prevents arcing and poor connections when intact and properly secured

What's included One wiring harness as shown Install notes

• Disconnect power at the breaker or unplug the appliance before starting
• Take photos of existing wire routing and connector orientation for reference
• Replace only with matching connector locations and wire colors; secure clips and strain reliefs
• If insulation is melted or connectors are corroded, inspect surrounding components for heat or electrical damage
