Frigidaire 316580474 Wiring Harness (Electrical) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316580474 replaces AP5330889, 2210903, AH3506373, EA3506373, PS3506373.

Description

This wiring harness routes power and signals between an appliance's electrical components to restore reliable operation and connector integrity. Replaces a damaged or corroded harness to help eliminate intermittent power and control faults. What it does:

• Provides the correct electrical connections between internal components and control modules
• Enables power and signal transfer for lights, switches, sensors, and motors
• Prevents open or shorted circuits caused by frayed or broken wires
• Common symptom: appliance won't power on, has intermittent operation, or some functions fail
• Used when connectors are melted, pins are loose, or wiring insulation is damaged

What's included: One wiring harness Install notes:

• Always disconnect power (unplug or shut off breaker) before servicing electrical parts
• Verify connector orientation and routing against OEM diagrams; avoid pin damage when connecting
• Route harness away from sharp edges, hinges, and heat sources; secure with OEM clips or ties
