Frigidaire 5304497428 Wire Harness (Wiring Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304497428 replaces AP5955416.

Description

This wire harness is the factory-style wiring assembly that connects and routes power and signals between refrigerator components for reliable operation. It restores proper electrical connections so fans, compressor and controls can operate as intended. What it does:

• Carries power and signal connections between control board, compressor, fans, sensors and other internal components
• Replaces damaged or brittle wiring that can cause intermittent operation or loss of function
• Helps resolve symptoms such as no power to components, intermittent fan/compressor operation, or electrical error codes linked to wiring faults
• Keeps connectors organized and routed to prevent chafing or pinching that can lead to shorts

What's included: One complete wire harness assembly as shown. Install notes:

• Disconnect power to the appliance before starting any work to avoid shock or injury
• Verify connector orientation and secure snaps; do not force connectors—match keyed ends
• Route harness following the appliance wiring diagram and secure with clips/fasteners to prevent contact with moving or hot parts
• Inspect adjacent components and replace any damaged connectors, grommets, or mounting hardware as needed
