Frigidaire 5304506051 Wiring Harness (Electrical) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304506051 replaces AP6041631.

Description

This wiring harness restores the electrical connections between the appliance's controls and its components so circuits can operate reliably. It replaces a damaged or worn harness to help resolve intermittent or lost power to connected parts. What it does:

• Carries power and signals between the control board and associated components
• Replaces frayed, broken, or corroded wiring that can cause intermittent operation
• Commonly addresses symptoms such as components not receiving power, intermittent failures, or tripped fuses/circuits
• Maintains correct routing and connector fit to prevent chafing and shorts

What's included: One complete wiring harness as shown. Install notes:

• Disconnect power to the appliance before starting any work to avoid shock or injury
• Match connectors and routing to the service diagram or factory wiring to ensure correct installation
• Inspect connectors and terminals for damage; replace or repair as needed rather than forcing mismatched plugs
