Frigidaire 5304509697 Wiring Harness (Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304509697 replaces AP6285879.

Description

This wiring harness connects electrical components inside the appliance to restore reliable power and signal paths for controls and sensors. It replaces a damaged or burned harness to help eliminate intermittent power or control failures. What it does:

• Carries power and control signals between the control board and components.
• Replaces frayed, burned, or corroded wiring that can cause intermittent operation or no power.
• Helps resolve symptoms such as unresponsive controls, lights that won't turn on, or components that fail to run.
• Restores correct connector fit and routing to prevent shorts or pinched wires.

What's included: One complete wiring harness assembly as shown. Install notes:

• Always disconnect power (unplug or shut off breaker) before starting repair.
• Compare the new harness to the old one to confirm connector types and lengths before installing.
• Route harness to match original path and secure with existing clips or ties to avoid contact with moving parts or heat sources.
