Frigidaire 5304516049 Wiring Harness (Electrical) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304516049 replaces AP6799863, 5304501426.

Description

This wiring harness provides the appliance's electrical connection between key components, restoring reliable power and signal routing for proper operation. It replaces damaged or worn wiring assemblies to help resolve intermittent power or control issues. What it does:

• Routes power and control signals between the control board and other components
• Restores proper electrical connectivity when wires are frayed, broken, or burned
• Can stop intermittent operation, failure to start, or unexplained error/alert conditions caused by wiring faults
• Prevents arcing and short circuits when damaged wiring is replaced

What's included:

• One wiring harness assembly

Install notes:

• Disconnect power to the appliance before starting any repair
• Match connector shapes and routing to the original harness during installation
• Handle connectors gently to avoid bending terminals; secure harness away from moving or hot parts
