Frigidaire 5304516119 Wiring Harness (Main) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304516119 replaces AP6783471, 5304501425.

Description

This wiring harness connects appliance controls and components to restore reliable electrical paths. It replaces a damaged or worn harness so switches, lights, motors, or sensors get proper power and signal routing. What it does

• Re-establishes electrical connections between control board and components.
• Restores power/signals to items like lights, motors, valves, or sensors when a broken harness causes intermittent or no operation.
• Prevents shorts and arcing that can occur from cracked insulation or loose terminals.
• Helps resolve symptoms such as no power to specific functions, intermittent operation, or visible damage to wiring.

What's included

• One complete wiring harness as shown.

Install notes

• Disconnect power (unplug or shut off breaker) before starting work.
• Verify wire routing and connector orientation before removing the old harness; take photos for reference.
• Secure harness with existing clips or ties; avoid contact with heat sources or moving parts.
