Frigidaire 5304517539 Wiring Harness (Electrical Connector Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304517539 replaces AP6802333, 316525629.

Description

This wiring harness routes power and signals between the appliance control and components to restore reliable electrical connections. It replaces a damaged or worn connector bundle to stop intermittent operation and restore proper function. What it does:

• Provides bundled wiring and connectors for power and control signal routing
• Replaces frayed, burned or broken wires and damaged connector ends
• Helps resolve intermittent power, unresponsive controls, or component failures tied to wiring
• Restores secure plug-and-play connections between circuit boards and components

What's included: One complete wiring harness with connectors as shown Install notes:

• Disconnect all power to the appliance before starting any repair
• Compare the new harness to the old one to confirm connector types and routing
• Route and secure the harness with clips or ties to prevent chafing or heat exposure
