Frigidaire 5304528828 Wiring Harness OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Switch.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304528828 replaces AP7014181, 5304506556, 5304510486.

Description

This wiring harness connects key components within the appliance, carrying power and control signals where they need to go. Replacing a damaged harness restores safe operation and fixes intermittent failures caused by loose, burnt, or broken connections.

• Routes electrical power and control signals between boards, switches, sensors, motors, and heaters
• Helps resolve symptoms such as won't start, stops mid-cycle, intermittent operation, dead components, breaker tripping, burning smell, or visible melted/brittle wiring
• Restores proper continuity when the original wiring is cut, overheated, corroded, or shorted
• Maintains correct electrical pathways to protect components from further damage

What's included: 1 wiring harness assembly. Install notes:

• Disconnect power before servicing; verify no voltage is present with a meter
• Document connector locations and wire routing; take photos for reference
• Release connector locking tabs—do not pull on wires; route in original path using existing clips/retainers, away from sharp edges, heat, and moving parts
• Ensure all terminals are fully seated; test operation before final reassembly
