Frigidaire 5304528829 Wiring Harness (Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304528829 replaces AP7014182, 5304520897.

Description

This wiring harness is the factory-style electrical assembly that routes power and signals between components to restore reliable operation. It replaces a damaged or worn harness to help re-establish proper connections and function. What it does

• Connects power and control signals between appliance components (motors, switches, controls, igniter, etc.).
• Replaces frayed, burned, or broken wires and damaged connector ends that can cause intermittent operation.
• Common symptom fixes: appliance won't start, heating elements or burners don't power up, or circuits show open/short conditions.
• Restores secure, color-coded connector fits to prevent poor contact and arcing.

What's included One complete wiring harness assembly as shown. Install notes

• Disconnect power at the breaker or unplug the appliance before beginning any work.
• Compare the new harness to the old one for routing and connector match before installation.
• Route and secure the harness away from heat sources and moving parts; use existing clips and fasteners.
