Frigidaire 5304519003 Wiring Harness Assembly (Replacement) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304519003 replaces AP6886174, 5304506252.

Description

A wiring harness assembly that replaces a damaged or faulty connector bundle to restore proper electrical connections between controls, sensors and components. Replaces worn wiring to help return reliable appliance operation. What it does

• Routes power and signal circuits between the control board and components so switches, sensors and motors operate correctly.
• Restores broken, burned or corroded connector paths that can cause intermittent operation or complete failure.
• Addresses symptoms such as no power to a circuit, intermittent cycles, error codes tied to lost connections, or visible wiring damage.
• Provides factory-style connector plugs and wire lengths to match OEM routing and contact points.

What's included

• One wiring harness assembly exact-match.

Install notes

• Disconnect power (unplug or shut off breaker) before service to avoid shock or damage.
• Compare the harness to the old part and note connector locations; label wires if needed for correct routing.
• Route and secure the harness per OEM clips/fasteners; avoid contact with sharp edges or hot surfaces.
