Frigidaire 5304517285 Harness Assembly (Wiring Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304517285 replaces AP6809029, 5304500988, 5304503413.

Description

This harness assembly is the factory-style wiring harness that connects electrical components to restore reliable electrical paths and component control. It replaces damaged or worn harnesses to stop intermittent or failed component operation. What it does:

• Provides factory routing and multi-pin connections between control, sensors, and powered components
• Restores power and signal continuity to components that are intermittent, dead, or non-responsive
• Prevents electrical shorts and poor connections caused by frayed or broken wires
• Maintains OEM-fit routing to reduce strain and interference with moving parts

What's included: One harness assembly as shown Install notes:

• Disconnect power (unplug or shut off breaker) before beginning any work
• Handle connectors by the housings, not the wires; avoid pulling on wires
• Route and secure harness with existing clips or fasteners to prevent pinching or abrasion
• If connectors are corroded or pins are bent, replace the harness rather than attempting repair
