Frigidaire 316528205 Main Wiring Harness (Primary Refrigerator Control Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316528205 replaces AP4433276, 1513477, AH2364103, EA2364103, PS2364103.

Description

This main wiring harness routes power and control signals between the refrigerator's control board and major components for reliable operation. It restores electrical connections so systems like cooling, fans, and defrost can operate correctly. What it does:

• Connects the control board to compressor, evaporator fan, condenser fan, lights, and defrost components
• Enables power and signal flow so cooling and defrost cycles run as designed
• Commonly replaced when loose/burned wires or damaged connectors interrupt operation
• Address symptoms such as no cooling, fans not running, interior lights out, or defrost failure

What's included:

• One main wiring harness

Install notes:

• Disconnect power to the appliance before starting any work
• Match connectors and routing to the original harness; do not force connectors
• Secure harness with original clips and fasteners to prevent rubbing or pinching
