Frigidaire 316580242 Main Wiring Harness (Electrical) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316580242 replaces AP4979633, 1864892, AH3490840, EA3490840, PS3490840.

Description

This main wiring harness routes power and control signals between the appliance control and major components, restoring reliable electrical connections and operation when the original harness is damaged or fails. What it does

• Distributes power and signal connections from the control board to components.
• Replaces frayed, burned, or broken wiring that can cause intermittent operation or complete loss of function.
• Commonly used when burners, oven, lights, or fans do not respond or the control board shows no output.
• Helps eliminate arcing, shorts, or electrical faults caused by damaged connectors or insulation.

What's included

• One main wiring harness

Install notes

• Disconnect all power before starting; verify the appliance is de-energized.
• Match connector locations and routing to the original harness; secure with existing clips or ties.
• Inspect related connectors and components for heat or corrosion damage; replace as needed.
