Frigidaire 241519901 Wiring Harness (Main Control-To-Component Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 241519901 replaces AP3769144, 1056505, AH976782, EA976782, PS976782.

Description

This wiring harness routes power and signals between the appliance control and its components, restoring reliable electrical connections for proper operation. Use this direct-fit replacement when the original harness is damaged or intermittent. What it does

• Provides dedicated wiring between the main control and motors, valves, switches or sensors
• Replaces brittle, frayed or burned wires that can cause intermittent operation or failed components
• Restores missing circuits that prevent the appliance from starting or running specific functions
• Helps stop electrical arcing and loss of connectivity when the original harness insulation is compromised

What's included

• One wiring harness

Install notes

• Disconnect power (unplug or switch off breaker) before beginning any repair
• Compare new harness to the old unit to verify routing and connector fit before installation
• Route and secure the harness away from moving parts and heat sources; use existing clips and ties
• If connectors are corroded or pins are damaged, replace connectors
