Frigidaire 242019602 Wiring Harness (Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 242019602 replaces AP5607774, AH3633280, EA3633280, PS3633280.

Description

This wiring harness assembly routes electrical power and signals between the appliance's control components, enabling reliable operation of motors, lights, and sensors. Replacing a damaged harness restores proper electrical connections and reduces risk of intermittent faults. What it does:

• Carries power and control signals between the control board, motors, switches, and sensors
• Fixes symptoms like intermittent operation, components that don't power on, or loss of specific functions
• Helps eliminate arcing, burning odors, or visible wire damage caused by frayed or broken conductors
• Maintains correct connector fit and wire routing to prevent shorts or pinched wiring

What's included:

• One wiring harness assembly

Install notes:

• Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
• Compare connectors and wire colors to the old harness before installing
• Route harness along original clips and channels; avoid sharp edges and moving parts
• If you see melted connectors or scorch marks, inspect adjacent components and replace affected parts as needed
