Frigidaire 5304521778 Wiring Harness (Main) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304521778 replaces AP6893118, 808772001.

Description

This wiring harness routes power and signals between the oven's control and key components to restore electrical connectivity and reliable operation. It replaces a damaged or burned harness to help eliminate intermittent or non-working controls. What it does:

• Connects the range/oven control board to switches, sensors, and power sources
• Restores missing or intermittent electrical connections that cause control failures
• Replaces frayed, melted, or damaged wires that can cause shorts or no power to components
• Helps resolve symptoms such as unresponsive control buttons, display issues, or burners/oven elements not receiving power

What's included:

• One wiring harness as shown

Install notes:

• Disconnect power at the breaker before starting work to avoid shock or damage
• Verify connector orientation and secure all plugs; loose connections can cause faults
• Inspect mounting clips and wire routing; avoid pinching wires when reinstalling panels
