Frigidaire 316575902 Oven Door Hinge OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Hinge.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316575902 replaces AP4499717, 1553964, AH2373550, EA2373550, PS2373550.

Description

This spring-loaded hinge supports and controls the oven door's movement so it opens smoothly and closes firmly, helping the door seal properly and retain heat. Replacing a worn hinge restores proper door alignment and closing force.

• Provides the pivot and spring tension for controlled door opening/closing
• Helps the door sit flush against the gasket to maintain a proper heat seal
• Common symptoms: door won't fully close, sags or drops, won't hold at a mid-open position, heat escaping from the front
• Typical causes of failure: metal fatigue, spring wear, or hinge deformation from heavy use

What's included: One hinge assembly. Install notes:

• Disconnect power; for gas models, also shut off gas. Allow the oven to cool completely.
• Support the door and engage hinge locks or remove the door.
• Springs are under tension—use gloves and eye protection; do not disassemble the hinge.
• Align with the receivers/slots and test for smooth operation and full closure; consider replacing both for even tension.
