Frigidaire 242093301 Dispenser Crusher Housing OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Housing Or Cover.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 242093301 replaces AP4982460, 1864476, AH3492956, EA3492956, PS3492956.

Description

This housing forms the framework of the ice crusher assembly inside the refrigerator's ice bucket. It holds and aligns the auger and crusher components so ice is crushed consistently and dispensed smoothly.

• Supports and positions the auger and crusher blades within the ice bin
• Guides ice through the crusher for consistent flow to the dispenser
• If damaged or worn, can cause: crushed ice not dispensing, cubes only, or jamming
• Can also lead to loud grinding noises or visible cracks/broken tabs in the ice bucket assembly

What's included: One dispenser crusher housing Install notes:

• Disconnect power before servicing; remove the ice bin from the freezer door
• Empty the bin and allow parts to acclimate to room temperature before disassembly
• Note the order and orientation of internal crusher parts; transfer them to the new housing as needed
• Use caution—crusher components can have sharp edges; ensure proper alignment before reinstallation
