Best Seller
Manufacturer Part

Frigidaire 316540701 Ignitor Orifice Assembly (Oven Burner) OEM Part

Manufacturer's Part Number: 316540701
Genuine Frigidaire part
Appliance Compatibility Tool
$23.24

Secure and trusted checkout with

Out Of Stock

Usually ships within 4 - 14 days

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316540701 replaces AP4481787, 316527901, 7316540701.

Description

This ignitor orifice assembly delivers gas to the oven burner and secures the ignitor, allowing reliable ignition and consistent baking or broiling heat. Replace a damaged or clogged assembly to restore normal oven lighting. What it does
  • Routes gas to the oven burner and positions the ignitor for proper ignition
  • Helps the ignitor light the burner so the oven reaches and holds set temperatures
  • Commonly used when the oven fails to light, the ignitor glows but no flame appears, or flame is weak/intermittent
  • Works as a direct-fit replacement for the original factory assembly
What's included
  • One ignitor orifice assembly
Install notes
  • Turn off electrical power and shut off the gas supply before starting work
  • Access usually requires removing the oven burner box or broiler drawer
  • Handle the ignitor and tubing carefully; damaged ignitors or bent fittings can cause malfunction or gas leaks

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Frigidaire 316540701 Ignitor Orifice Assembly (Oven Burner) OEM Part

Part Number:
OEM13445370
Manufacturer's Part Number:
316540701

Fits 18 models

ManufacturerModel NumberDescription
ElectroluxEW3LDF65GBDRANGE
ElectroluxEW3LDF65GSERANGE
ElectroluxEW3LDF65GSGRANGE
ElectroluxEW3LDF65GSHRANGE
ElectroluxEW3LDF65GSJRANGE
ElectroluxEW3LDF65GSKRANGE
ElectroluxEW3LDF65GSNRANGE
ElectroluxEW3LDF65GWDRANGE
ElectroluxEW3LGF65GBDGAS RANGE
ElectroluxEW3LGF65GSFGAS RANGE
ElectroluxEW3LGF65GSGGAS RANGE
ElectroluxEW3LGF65GSHGAS RANGE
ElectroluxEW3LGF65GSJGAS RANGE
ElectroluxEW3LGF65GSKRANGE
ElectroluxEW3LGF65GSMRANGE
ElectroluxEW3LGF65GWDGAS RANGE
FrigidaireFCRL3052ASCFRIGIDAIRE-LP-RANGE
ElectroluxFCRL3052ASDRange
