Frigidaire 808364721 Compressor Inverter OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 808364721 replaces AP6301829, 4585451, 808364712, PS12366363.

Description

This compressor inverter module powers and controls a variable-speed refrigerator compressor. When the inverter fails, the compressor may not start or modulate correctly, leading to warm temperatures or intermittent cooling. Replacing the module restores proper compressor drive.

• Converts AC line power to controlled 3-phase output for the variable-speed compressor
• Receives commands from the main control to start and regulate compressor speed
• Typical failure symptoms: refrigerator/freezer warm, compressor not running though fans/lights work, brief humming/clicking then stopping, intermittent cooling, or inverter/compressor error indications
• Mounts externally near the compressor and connects to the control harness and compressor terminals

What's included: One compressor inverter module Install notes:

• Disconnect power before servicing; high voltage is present at the inverter
• Access the rear lower compartment; transfer connectors one at a time to the new module and ensure tight terminal fits
• Reinstall on the original bracket/position to maintain cooling and ventilation around the inverter
• Restore power and allow up to 24 hours for temperatures to stabilize after repair
