Frigidaire 242219204 Evaporator Fan Motor (Freezer) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 242219204 replaces AP6041603, 4546153, PS11775575.

Description

This evaporator fan motor drives the freezer fan that moves cold air across the evaporator and throughout the compartments. Replacing a failed motor restores proper airflow for steadier temperatures, faster cooling, and fewer warm spots.

• Circulates air over the evaporator coils and through the freezer and fresh-food sections to maintain even cooling
• Helps reduce temperature swings by keeping air moving across the coils
• Failure may present as little or no airflow from vents, refrigerator warm while freezer is cold, or frost/ice accumulating behind the rear freezer panel
• Noisy, grinding, or intermittent fan operation can also indicate a worn motor

What's included: 1 evaporator fan motor

• Disconnect power and wear cut-resistant gloves before servicing
• Access from the freezer: remove shelves/bins and the rear evaporator cover to reach the fan assembly
• Transfer the existing fan blade, bracket, and grommets from the original motor; ensure correct blade orientation and free spin
• Seat the wiring connector fully and route wires clear of the fan before reassembly
