Frigidaire 318168114 Medium Burner Pan OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Drip Pan.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 318168114 replaces AP2129069, 782397, AH444058, EA444058, PS444058.

Description

This is a medium burner pan that is used with ranges and stoves. The burner pan is located under the heating unit to catch any drips and spills. This prevents the drips from reaching the internal components of the stove where they could cause additional damage. Over time, the burner pan can be overly soiled and damaged and may need to be replaced. The process of replacing the medium burner pan takes only a few minutes. The first step is to unplug the stove or range. Next, the elements on the cooktop need to be lifted to access the parts underneath. The burner pan will be found in one of the cavities under the burners. These can be removed by hand and set aside. When replacing the burner pan, make sure the hole on the side is oriented to fit the terminals. Plug the elements back in and plug in the stove.The medium burner pan is made for use with ovens, ranges, and stoves manufactured by Kenmore and Frigidaire. It is sold as an individual product. This is an authentic OEM replacement part that is sourced directly from the manufacturer.
