Frigidaire 5304532180 Main Power Board Assembly OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304532180 replaces AP7194882.

Description

This main power board assembly manages incoming power and switches key components on and off. Replacing a failed board restores stable power distribution and dependable operation when the appliance is dead, erratic, or repeatedly shuts down.

• Receives AC power and provides controlled output to the appliance's control circuits and major loads
• Activates relays/outputs to run components as directed by the control system
• Helps stabilize and protect onboard circuits from minor power fluctuations
• Common symptoms include: no power, intermittent operation, dead display/lights, clicking from the board, or visible burn marks on the PCB

What's included: 1 main power board assembly Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD precautions and handle the board by its edges
• Photograph wiring and move connectors one at a time, confirming keyed orientation and secure seating
• Reuse existing mounting hardware; after installation, restore power and perform any model-specific reset or diagnostic checks.
