Frigidaire 5304523755 Reed Switch Harness (Wire Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304523755 replaces AP7176924.

Description

This reed switch harness connects a reed-style door or lid sensor to the appliance's control, restoring reliable open/close sensing and related functions. It replaces a damaged or broken harness to help reestablish proper sensor signals. What it does:

• Provides the electrical connection between the reed (magnetic) sensor and the control board
• Restores door/lid open-close sensing used for lights, safety interlocks, or cycle control
• Commonly fails when wiring is frayed, connectors are loose, or the harness is damaged
• Symptoms include no interior light, intermittent sensor behavior, or control errors tied to door/lid sensing

What's included: One reed switch harness as pictured. Install notes:

• Disconnect power to the appliance before beginning work to avoid shock or damage
• Handle connectors gently and ensure mating terminals are fully seated
• Route and secure the harness following existing clips or channels to avoid pinching or heat exposure
