Frigidaire 218659600 Service Data Sheet (Repair Information Sheet) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Manual, Care Guide.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 218659600 replaces AP2114871, 451573, AH428401, EA428401, PS428401.

Description

This service data sheet provides the factory service and diagnostic information technicians use to troubleshoot and repair appliances. It includes key wiring, calibration, and specification details so repairs are accurate and faster. What it does:

• Summarizes system wiring, component locations, and electrical ratings for reference during service
• Lists control settings, diagnostic codes, and test points to help identify failures
• Clarifies manufacturer-recommended adjustments and calibration values
• Supports correct part selection and verification of symptom causes

What's included: One printed service data sheet (single information sheet) Install notes:

• For technician use only; read entire sheet before beginning repair
• Keep sheet dry and with the appliance or service records for future reference
• Follow all safety precautions and disconnect power before testing or servicing
• Use the sheet alongside the appliance's official service manual and wiring diagrams
