Frigidaire 316441709 Service Tech Sheet (Diagnostic Guide) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Manual, Care Guide.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316441709 replaces AP3963504, 1197097, AH1528130, EA1528130, PS1528130.

Description

This service tech sheet is the factory diagnostic guide that helps troubleshoot and verify appliance components. It provides clear reference information technicians use to identify wiring, error codes, and common diagnostic steps for repairs. What it does:

• Shows factory wiring diagrams and component locations for quick reference during diagnosis
• Lists common error codes and troubleshooting checks to narrow down failures
• Provides step-by-step diagnostic guidance technicians use to confirm faulty parts
• Helps reduce guesswork when an appliance won't power on, shows error codes, or has intermittent operation

What's included: One printed service tech sheet. Install notes:

• This is a reference document, not a wearable or electrical component; store it in a dry, accessible place near the appliance
• Always disconnect power to the appliance before performing any testing or repairs suggested by the sheet
• Follow all safety guidance and manufacturer procedures shown on the sheet; use protective equipment as required
• Replace the sheet if damaged or illegible to ensure accurate diagnostics
