Frigidaire 241707721 Compressor Start Relay (Ptc) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Relay, Overload, Capacitor.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 241707721 replaces AP4419352, 1512603, AH2358714, EA2358714, PS2358714.

Description

This compressor start relay (PTC) briefly powers the compressor's start winding to ensure reliable start-up. Replacing a failed relay can stop repeated clicking and help a non-starting compressor restore normal refrigerator cooling.

• Provides a timed, resistance-based boost to the compressor's start winding, then drops out of the circuit
• Common symptoms: compressor hums then clicks off, frequent clicking from the rear, warm fridge/freezer, intermittent cooling
• Mounts directly on the compressor terminals; works with the separate overload protector and, if equipped, a run capacitor
• Visible signs of failure may include heat damage, burnt odor, or loose/rattling pieces inside the old relay

What's included: 1 PTC start relay Install notes:

• Unplug the refrigerator and remove the lower rear access panel to reach the compressor
• Note wire routing and orientation; transfer any harness/retainer and seat the relay fully on the compressor pins
• If a run capacitor is present, discharge it before handling and reconnect to the same terminals
• Inspect the overload and connectors; replace any heat-damaged components
