Frigidaire 134048900 Control Thermostat (Dryer) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dryer Fuse Or Sensor.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 134048900 replaces AP3214939, 131637800, 916702, AH419279, EA419279, PS419279.

Description

This control thermostat regulates the dryer's operating temperature. It senses exhaust air heat and cycles the heater on and off to maintain consistent drying performance and help protect the appliance from overheating. What it does:

• Monitors exhaust temperature and controls the heating element to hold the selected heat level
• Helps prevent overheating by cycling heat off when the target temperature is reached
• Supports even drying and consistent cycle times
• Typical failure symptoms: no heat or not enough heat, long dry times, runs too hot, inconsistent temperatures

What's included:

• 1 control thermostat

Install notes:

• Disconnect power before servicing; if gas, also shut off the gas supply
• Access location varies by model; typically mounted on the heater housing or exhaust duct
• Transfer wire leads one at a time to the new thermostat and secure with the original screws
• After reassembly, clean the lint path and ensure good airflow to prevent repeat failures
