Product Details
Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore
Cross Reference Information
Part Number 5303934089 replaces AP2150391, 08003132, 08008683, 08008877, 08012753, 3051726, 3051793, 3051852, 3200796, 5301325330, 5303200796, 5303208690, 5305119401, 638071, 8012753, AH470079, DK1324349, DK1325330, EA470079, K001316715, K001324349, K001325006, K001325330, K005036801, K1312565, K1313739, K1314633, K1315534, K1315538, K1316567, K1316715, K1317024, K1317556, K1317811, K1318981, K1321087, K1321166, K1321286, K1322611, K1323640, K1324346, K1324349, K1324350, K1324495, K1325006, K1325330, K5068201, K5119401, K5272201, PS470079.
Description
This mechanical cycle timer controls the timed sequencing of a laundry appliance's wash and spin cycles, restoring user control over cycle selection and progression. It replaces a worn or non-advancing console timer for reliable cycle timing. What it does:
- Advances and times cycle stages so wash, rinse and spin steps run in the correct order
- Selects cycle options when the console dial is turned or pushed
- Replaces a timer that won't advance, won't start cycles, or has intermittent control
- Works with the appliance's existing wiring harness and dash controls to restore normal operation
What's included:
- One mechanical cycle timer
Install notes:
- Disconnect power before beginning any repair to avoid electrical shock
- Turn off water supply and remove access panels as needed for safe access
- Carefully note or photograph wire connections before removal and reconnect wires to matching terminals
