Product Details
Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
See all items in Washer Dryer Combo Gearcase and Washer Gearcase.
Electrolux also makes various appliance models for Sears / Kenmore
Cross Reference Information
Part Number 134736400 replaces AP3892125, 08014910, 08027583, 1191298, 131878401, 131878411, 134588801, 134612101, 3161176, 5308014910, 5308057579R, AH1524604, EA1524604, F140716-000, F140716000, F141133-000, F141133000, PS1524604, Q000199044, Q199044, Q199046.
Description
This transmission assembly drives the agitation and spin cycles by transferring motor power to the tub. Replacing a worn transmission helps restore proper wash action and spin performance.
- Converts motor rotation into the geared motion needed for wash (agitate) and spin
- Shifts between agitation and spin modes during the cycle
- Common failure signs: no or weak agitation; no spin or slow spin
- Other symptoms include loud grinding/rumbling, oil leaking from the center area, or the motor running while the tub doesn't move
What's included: 1 transmission assembly Install notes:
- Disconnect power and water; move the appliance to a stable work area and use proper lifting support
- Access the drive assembly from below; support the tub/frame to prevent tipping
- Mark component orientation, remove fasteners and drive components as needed, and transfer any reusable parts from the original unit
- Tighten mounting hardware evenly, then run a test cycle and check for leaks
