Frigidaire 5304533910 Feed Tube Assembly (Dishwasher Rear Water Supply) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304533910 replaces AP7215604.

Description

This feed tube assembly carries wash water up the back of the tub to the upper spray system. Replacing a cracked or clogged tube restores proper spray pressure and helps recover upper-rack cleaning performance while preventing leaks from the rear wall.

• Directs water from the pump/sump to the middle/top spray system
• Maintains a sealed path at rear connections to prevent leaks
• Helps ensure proper spray pressure and coverage to clean the upper rack
• Typical symptoms: weak or no spray on the upper rack, leaks from the rear wall, visible cracks, broken mounting tabs, or the tube not staying latched

What's included: One feed tube assembly. Install notes:

• Disconnect power at the breaker and turn off the dishwasher's water supply
• Open the door; remove the upper rack if needed for access
• Remove rear fasteners/clips, disengage the tube from the sump/manifold, and transfer any seals or clips
• Seat the new tube fully, secure fasteners, restore power/water, and run a short cycle to check for leaks
