Frigidaire 137465100 Water Inlet Valve (3-Coil) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Washer Valve.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 137465100 replaces AP5656783, 2688979, PS6012202.

Description

This triple-solenoid washer water inlet valve regulates and routes hot and cold water into the tub and dispenser as the control commands. Replacing a weak, stuck, or leaking valve restores proper fill, temperature mix, and cycle performance. What it does:

• Opens and closes to allow water into the washer based on cycle and temperature selections
• Three solenoids manage hot/cold mix and direct water to the tub and dispenser compartments
• Typical symptoms: won't fill, slow fill, fills when powered off, incorrect temperature, or leaks from the valve
• May trigger fill-related error codes or cause extended/paused cycles due to fill timeout

What's included:

• One water inlet valve assembly with three solenoids

Install notes:

• Disconnect power and turn off both hot and cold water supplies before servicing
• Place a towel or shallow pan to catch residual water when removing hoses
• Label and transfer each wire connector and hose to the matching port on the new valve
• After installation, open supply valves and run a test fill; inspect all connections for leaks
